2010 Kawasaki Ninja ZX-6R - Specification

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R is the newest 600cc class with spotbike. No vehicle capable or better, which is needed and can do anything other than Kawasaki Ninja ZX-6R. With the new technology that accompanies it, a technology based on the data available on the Kawasaki ZX-RR 800cc motogp. Also the design in 2010 Kawasaki Ninja ZX-6R is made as thin as possible so that more light, a stable balance without destroying aerodynamic systems that already exist. Along with the lightweight and compact design, the Ninja ZX-6R machine packed with detail to provide precise throttle control and exceptional performance, especially in the mid-range. With so dispatch of a more refined and optimized, it means control of the vehicle will be easy because the engine did not go wild. All of this has to be a future project which not only thinking kawasaki speed but many aspects that will make drivers more comfortable. 2010 Kawasaki Ninja ZX-6R will be sold on the market at a price of $ 10,499, but before you buy a better look at the data the information below, including features and specifications are on the 2010 Kawasaki Ninja ZX-6R.

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R - Specifications
MSRP $10,499 USD
  • Engine: Four-stroke, liquid-cooled, DOHC, four valves per cylinder, inline-four
  • Displacement: 599cc
  • Bore x stroke: 67.0 x 42.5mm
  • Compression ratio: 13.3:1
  • Fuel injection: DFI® with four 38mm Keihin throttle bodies, oval sub-throttles, two injectors per throttle body
  • Ignition: TCBI with digital advance
  • Transmission: Six speed
  • Final drive: X-ring chain
  • Rake / trail: 24 deg / 4.1 in.
  • Frame type: Aluminum perimeter
  • Front tire: 120/70 ZR17
  • Rear tire: 180/55 ZR17
  • Wheelbase: 55.1 in.

Front suspension / wheel travel: 41 mm inverted Showa Big Piston Front fork with top-out springs, stepless compression and rebound damping, fully-adjustable spring preload / 4.7 in.

Rear suspension / wheel travel: Bottom-Link Uni-Trak® with gas-charged shock, top-out spring and pillow ball upper mount, dual-range (high/low-speed) stepless compression damping, 25-way adjustable rebound damping, fully-adjustable spring preload / 5.3 in.

  • Front brakes: Dual 300mm petal rotors with dual radial-mounted, four-piston, four-pad calipers
  • Rear brake: Single 220mm petal rotor with single-piston caliper
  • Overall length: 82.3 in.
  • Overall width: 28.0 in.
  • Overall height: 43.9 in.
  • Fuel capacity: 4.5 gal.
  • Seat height: 32.1 in.
  • Curb weight: 421.2 lbs.
  • Color choices: Passion Red, Metallic Spark Black, Lime Green/Metallic Spark Black
  • Warranty: 12 Months
  • Good Times™ Protection Plan 12, 24, 36 or 48 months

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R

2010 Kawasaki Ninja ZX-6R

Features and Benefits for 2010 Kawasaki Ninja ZX-6R :
Advanced Suspension
  • The ZX-6R swingarm uses many of the same parts as the ZX-10R; both left and right inner plates, the left outer plate, rear stand bosses, brake caliper stopper, chain guard and swingarm pivot shaft
  • ZX-6R features Showa's Big Piston Front fork (BPF) design, for fantastic braking and initial corner turn-in
  • The large-diameter of the BPF's internal piston allows a reduction in damping pressure, for better feedback and smoother action
  • The BPF eliminates many of the internal components used in a cartridge-type fork, simplifying construction and resulting in lighter overall fork weight

Additional Features
  • Inner fender above the swingarm helps to reduce turbulence and keeps the undertail clean
  • Position lamps are integral with the projector beam headlights; the Ninja ZX-6R features dual position lamps like the ZX-10R
  • Similar in design to that of the ZX-10R, the instrument panel gives at-a-glance information to the rider
  • One-piece fender offers excellent aerodynamics
  • Highly evolved fairing for great wind protection, minimal cross-wind effects
  • Front brake hose routing with a three-way joint at the lower triple-clamp facilitates bleeding air from the brake lines

Massive Mid-Range Performance
  • Exhaust collector layout contributes to superb low and mid-range performance while maintaining high-rpm performance
  • Molybdenum-coated piston skirts for reduced friction and engine break-in
  • Cam and tappets nitriding enables high-load cam profiles, for maximum performance
  • Crown-finished pistons
  • Double bore velocity stacks feature inlets at two different heights, for increased performance in both the mid- and high-rpm ranges
  • Low-tension piston rings reduce mechanical loss
  • Advanced cam chain guides stabilize chain motion and further reduce mechanical loss

Tuned Chassis Balance and Mass Centralization
  • Exhaust pre-chamber further contributes to mass centralization
  • Engine is rotated forward around the output shaft for steeper intake angle and excellent CG
  • Exhaust layout with a short side muffler keeps the weight low
  • Frame stiffness around the swingarm pivot and the rear engine mounts optimizes front-rear rigidity balance

More Precise Throttle Control
  • Long throttle bodies between oval sub-throttles and round main throttles yield a smooth intake transition, for reduced inlet turbulence and increased efficiency
  • Advanced cylinder porting delivers excellent cylinder-filling and scavenging
  • Cylindrical guides in the top of the air cleaner box ensure accurately sprayed fuel mist from the secondary injectors into the intake funnels, improving combustion efficiency
  • High-current secondary coil circuitry for optimum combustion efficiency

Lightweight Engine
  • Inlet pressure pulse monitor does away with cam angle sensor, further contributing to lightness
  • Camshafts are made of chrome-moly steel
  • Lightweight transmission gears and gear dogs
  • Lightweight magnesium engine covers are standard
  • Cassette-type transmission makes it easy to quickly swap gear ratios, reducing set-up time at the track
  • Lightweight top injector mounting plate
  • Lightweight oil pump and starter gears

Lightweight Chassis
  • Intake resonator box and supports for the instrument panel and mirrors are unitized with the Ram Air duct, contributing to weight savings and increased rigidity
  • The lightweight sub-frame is very narrow, for a compact and slim rear end
  • The sub-frame is a 2-piece aluminum die-casting consisting of a front and rear section

Race-Quality Steering Damper
  • A race-quality adjustable Öhlins steering damper with relief valve and twin-tube design is fitted as standard equipment

Ergonomics and Chassis Feedback
  • Sculpted seat allows the rider to shift his body far back on the rear seat step, helping to reduce rider fatigue
  • Slim-waisted fuel tank makes it easy for the rider to grip the tank with his knees or to hang off in turns
  • Fuel tank profile is flared around its top, similar to the ZX-10R, providing a large contact patch for excellent rider feedback
  • Rear brake master cylinder reservoir forward of the swingarm mount frees up space around the footpeg, for simplicity and weight savings
  • Seat-pegs-bar relationship places handlebars close to the rider and turned in slightly for a highly intuitive riding position
  • Steep rake angle for quick steering response and enhanced communication from the front tire
