2010 Suzuki GSX-R750
2010 Suzuki GSX-R750 comes with a new model and features of the previous series. Some of the improvements and changes are made to make a better and perfect that motorists will be more comfortable. Because customer satisfaction is a goal you are creating this vehicle. Suzuki GSX-R750 has a 750cc engine, Compact 4-stroke, 4-cylinder, liquid-cooled engine designed for optimum combustion efficiency and maximum power delivery. In the Suzuki GSX-R750 also added some important features such as digital instruments, Electronic fuel injection system features Suzuki Dual Throttle Valve (SDTV) fuel injection system that will make the distribution of power at maximum engine and more optimal, and for the features along with its function you can see below along with the existing specifications on the 2010 Suzuki GSX-R750.
2010 Suzuki GSX-R750
2010 Suzuki GSX-R750
2010 Suzuki GSX-R750
2010 Suzuki GSX-R750
2010 Suzuki GSX-R750 - Specifications
Engine:
- Bore Stroke 70.0 mm (2.756 in) x 48.7 mm (1.917 in)
- Compression Ratio 12.5 : 1
- Engine 750cc (45.8 cu. In), 4-stroke, liquid-cooled, DOHC
- Fuel System Fuel Injection
- Ignition Electronic ignition (Transistorized)
- Lubrication Wet sump
- Starter Electric
Chassis:
- Colour Blue/White, Brown
- Brakes Front Disc brake, twin
- Brakes Rear Disc brake
- Curb Weight 198 kg (437 lbs)
- Final Drive Chain
- Fuel Tank Capacity 17.0 L (4.5/3.7 US/Imp gal)
- Ground Clearance 130 mm (5.1 in)
- Overall Length 2040 mm (80.3 in)
- Overall Width 715 mm (28.1 in)
- Seat Height 810 mm (31.9 in)
- Suspension Front Inverted, telescopic, coil spring, oil damped
- Suspension Rear Link type, coil spring, oil damped
- Tires Front 120/70ZR17M/C (58W), tubeless
- Tires Rear 180/55ZR17M/C (73W), tubeless
- Transmission 6-speed constant mesh
- Wheelbase 1405 mm (55.3 in)
Key Features:
- Instruments - Compact, lightweight instrument cluster features step motor controlled analog Tachometer, LCD speedometer, dual trip meters, clock and a comfortable position indicator teeth
- S-DMS engine managem - S-DMS engine management system that allows drivers to select from three engine settings to match up with the conditions attached handlebar switch
- Adjustable Footpegs - Three ways tailored footpegs now feature die-cast construction and can be moved into the three different positions with a 14mm horizontal and vertical range
- LED Tail Light - Combination LED taillights and brake lights built into the back of tailsection, displaying a red, mirror lens, covering the LED light.
- Compact 4-stroke, 4-cylinder, liquid-cooled engine designed for optimum combustion efficiency and maximum power delivery
- Fuel Injection - fuel injection system features Suzuki Dual Electronic Throttle Valve (SDTV) system - with dual fuel injections per cylinder and a new compact 8 hole, either spray injectors for improved fuel atomization.
- Bold Headlight - The GSX-R750 features a sharp and aggressive look with bold lighting design, point of the tail and compact overall layout.
- Titanium Lightweight titanium valves with steel springs and aluminum alloy spring retainers operated by thin wall hollow camshafts to reduce weight and inertia
- Steering Damper - steering damper which uses electronically controlled solenoid valves to move the needle pointed reducing or increasing oil flow to adjust damping force.
- Bold Headlight - The GSX-R750 features a sharp and aggressive look with bold lighting design, point of the tail and compact overall layout.
- High volume exhaust - high volume Suzuki Advanced Exhaust System (SAES) with an innovative under engine room that leads to a large volume muffler with a clear triangular silencer
